30mm Cage Cube Connector

This cube Connector Compatible with 30mm Cage Cubes, the center of the 530044 is with Φ26.4mm through hole, designed for connecting two cage cubes. Two Φ2.37 mm*6.5 mm Alignment Pins ensure that the center of the round hole is aligned with the center of the SM1 threaded hole of the cage cube.

Product characteristics
1. Compatible with 30mm Cage Cubes.
2. Center has a Φ26.4mm through hole.
3. 530045 is used to connect 530012 and 530013 cage cubes.

Products Related Download

Alignment Pins

Select..  

 M3

Clear

Pro No.

Parameter

Alignment Pins

Delivery time

Compare

Price

Purchase

530044

Parameter list

In stock



$23.33



530045

Parameter list

In stock



$23.33


