Optical Fiber Collimator
Collimator connectors effectively combine precision moulded glass aspheric lens and standard optical fiber connector together. The device has an external thread that can be connected to optical platform or instrument. Grand Unified Optics offers Optical Fiber Collimator & Optical Fiber Coupler with FCPC、FCAPC and SMA joint for your applications
Optical Fiber Collimator
Focal Length Tolerance ±1%
Diameter Tolerance ±0.015mm
Surface Quality 40/20(Scratch/Dig)
Diameter>10.00mm, Surface Quality 60/40
Pro No.
Parameter
Dia
Wavelength
Beam Diameter
Mount
Delivery time
Compare
Price
Purchase
11mm
543nm
1.2mm
FCPC
Consult
Consult
11mm
633nm
1.2mm
FCPC
Consult
Consult
11mm
780nm
1.2mm
FCPC
Consult
Consult
11mm
1064nm
1.4mm
FCPC
Consult
Consult
11mm
1310nm
1.1mm
FCPC
Consult
Consult
11mm
1550nm
1.2mm
FCPC
Consult
Consult
11mm
543nm
2.2mm
FCPC
Consult
Consult
11mm
633nm
2.1mm
FCPC
Consult
Consult
11mm
780nm
2.2mm
FCPC
Consult
Consult
11mm
1064nm
2.4mm
FCPC
Consult
Consult
11mm
1310nm
2.0mm
FCPC
Consult
Consult
11mm
1550nm
2.1mm
FCPC
Consult
Consult
11mm
543nm
0.9mm
FCPC
Consult
Consult
11mm
633nm
0.8mm
FCPC
Consult
Consult
11mm
780nm
0.9mm
FCPC
Consult
Consult
11mm
1064nm
1.0mm
FCPC
Consult
Consult
11mm
1310nm
0.8mm
FCPC
Consult
Consult
11mm
1550nm
0.9mm
FCPC
Consult
Consult
12mm
543nm
1.6mm
FCPC
Consult
Consult
12mm
633nm
1.5mm
FCPC
Consult
Consult
