20mm 1" 5M Fixed Focal Length Lens

Price Option

Product No. 600029

Stock In Stock

Express DHL, Fedex etc.

Quantity

Add car Chating online

Product file downloadClick file to download

3D View CAD PDF Auto CAD DXF eDrawing Step Datesheet

Parameters Specification Data curve Related Products Description

Focal Length 20mm

F/# 1.6

Max. sensor size 1"

Mount C

Resolution 5MP

Working Distance 0.5m～∞

Filter Thread M39x0.5mm

FOV 44.74°×36.08°×27.24°

Distrotion -2.87%@y=8.0mm

Weight 169g

No.	Item		Specifications
1	Max. sensor size		1"(16mm)
2	Focal Length		20mm
3	Mount		C-Mount
4	F/#		F1.6-F22
5	Working Distance		0.5m～∞
6	FOV(Diagonal x H xV)	1"	44.74°×36.08°×27.24°
		1/2"	22.82°×18.19°×13.83°
		1/3"	17.12°×13.72°×10.30°
7	Object Size (at the minimum focus distance)	1"	410.178×324.092×243.068mm
		1/2"	202.558×162.046×121.534mm
		1/3"	151.918×121.534×91.15mm
8	BFL（in air）		12.20mm
9	Operation	Focus	Manual
		Aperture	Manual
10	Distortion	1"	-2.87%@y=8.0mm
		1/2"	-0.72%@y=4.0mm
		1/3"	-0.41%@y=3.0mm
11	Filter thread		M39×0.5mm
12	Lens Size(W x L)		48.65×61.24mm
13	Weight		169g
14	Work Temperature		-20℃～+60℃
15	Distance of entrance pupil		26.58mm
16	Diameter of entrance pupil		12.50mm
17	Distance of exit pupil		-33.84mm
18	Diameter of exit pupil		21.14mm
19	Total optical length		69.44mm
20	Magnification		-0.040

Focus Distance	Magnification	Front DOV(mm)	Back DOV(mm)
500mm	-0.03950	7.3265	7.5477
550mm	-0.03594	8.8522	9.1466
600mm	-0.03298	10.5194	10.9017
650mm	-0.03046	12.3277	12.8137
700mm	-0.02831	14.2764	14.8834
750mm	-0.02644	16.3648	17.1116
800mm	-0.02480	18.5925	19.4988
850mm	-0.02335	20.9587	22.0459
900mm	-0.02206	23.4630	24.7536
950mm	-0.02091	26.1046	27.6226

Curve Download

16mm 1" 5M Fixed Focal Length Lens

20mm 1" 5M Fixed Focal Length Lens

25mm 1" 5M Fixed Focal Length Lens

35mm 1" 5M Fixed Focal Length Lens

1" 5M FA Lens designed with 1" sensor, maximum imaging size up to 16mm. This series lens have high cost performance, focal length covers 12mm,16mm,20mm,25mm,35mm.
