75mm 2/3" 5M Fixed Focal Length Lens
Share
WeChat
Scan and add Wechat

75mm 2/3" 5M Fixed Focal Length Lens

Price Option
 € 182.44 (EUR) ￡155.41 (GBP) ￥1070.00 (RMB)

Product No. 600013

Stock In Stock

Express DHL, Fedex etc.

Quantity
Add car Chating online
Product file downloadClick file to download
3D View CAD PDF Auto CAD DXF eDrawing Step Datesheet
Parameters Specification Data curve Related Products Description
Focal Length 75mm
F/# 2
Max. sensor size 2/3"
Mount C
Resolution 5MP
Working Distance 0.9m～∞
Filter Thread M40.5x0.5mm
FOV 8.4°×6.7°×5.0°
Distrotion 0.02%@y=5.5mm
Weight 223g
  No. Item Specifications
1 Max. sensor size 2/3"(11mm）
2 Focal Length 75mm
3 Mount C-Mount
4 F/# F2.0-F22
5 Working Distance 0.9m～∞
6 FOV(Diagonal x H xV) 2/3" 8.4°×6.7°×5.0°
1/2" 6.1°×4.9°×3.7°
1/3" 4.6°×3.7°×2.7°
7 Object Size
(at the minimum focus distance)		 2/3" 123.2×98.5×73.9mm
1/2" 89.6×71.7×53.8mm
1/3" 67.2×53.8×40.3mm
8 BFL（in air） 13.76mm
9 Operation Focus Manual
Aperture Manual
10 Distortion 2/3" 0.02%@y=5.5mm
1/2" 0.04%@y=4.0mm
1/3" 0.03%@y=3.0mm
11 Filter thread M40.5×0.5mm
12 Lens Size(W x L) 49.5×76.75mm
13 Weight 223g
14 Work Temperature -10℃～+50℃
15 Distance of entrance pupil 98.72mm
16 Diameter of entrance pupil 37.50mm
17 Distance of exit pupil -37.94mm
18 Diameter of exit pupil 18.97mm
19 Total optical length 85.73mm
20 Magnification -0.0893

Focus Distance Magnification Front DOV(mm) Back DOV(mm)
900mm -0.08930 1.4664  1.4712
950mm -0.08427 1.6337  1.6394
1000mm -0.07978 1.8101  1.8166
1050mm -0.07574 1.9954  2.0030
1100mm -0.07210 2.1898  2.1985
1150mm -0.06879 2.3931  2.4031
1200mm -0.06577 2.6055  2.6169
1250mm -0.06300 2.8269  2.8398
1300mm -0.06046 3.0573  3.0718
1350mm -0.05811 3.2967  3.3129
Curve Download

8mm 2/3" 5M Fixed Focal Length Lens

12mm 2/3" 5M Fixed Focal Length Lens

16mm 2/3" 5M Fixed Focal Length Lens

25mm 2/3" 5M Fixed Focal Length Lens
2/3" 5M FA lens has excellent optical performance. Features with Large aperture design, low distortion, high uniformity and the whole imaging area has a high resolution. Focal lengths included 8mm, 12mm, 16mm, 25mm, 50mm, and 75mm, it meet the application of users for different FOV and working distance.

Product characteristics
1. 5 Mega pixels, 2/3" optical format，150lp/mm@±5.5mm;
2. Focal length covering 8-75 mm;
3. Large aperture design, high transmission;
4. Special designed for high resolution cameras, central and edge resolution up to 3.45 um;
5. Powerful optical performance, Capable of complex tasks.
