Post-Mounted Iris Diaphragms

The aperture adjustment range of the Post-Mounted Iris Diaphragm is Φ1 mm~Φ25 mm, and the diaphragm aperture can be adjusted by the lever; the adjustable diaphragm is generally used to control the beam diameter, and its position and the size of the clear aperture will directly affect the entire optical system. brightness, sharpness, and aberrations.

Product characteristics
1. Lever-Actuated, Continuously Variable Iris
2. Black Spring Steel Leaves
3. Black-Anodized Aluminum Housing
4. Mounted on 75 mm Long Post

Products Related Download

Pro No.

Title

Parameter

Delivery time

Compare

Price

Purchase

528000

Post-Mounted Iris Diaphragms Max Aperture 12mm

Parameter list

In stock



$56.00



528001

Post-Mounted Iris Diaphragms Max Aperture 25mm

Parameter list

In stock



$60.00


