 60 mm Cage Right-Angle Mirror Mount

60 mm Cage Right-Angle Mirror Mount

GU Optics's Right-Angle Kinematic Mounts are designed for easy integration into our 60 mm cage system. All of these mounts have SM2-threaded bores on the entrance and exit ports for lens tube integration. The inclined surface is used to install Φ50.8 mm optical components with a minimum thickness of 6 mm, and fixed by locking screws. With three Adjusters to realized ±4º Tip and Tilt Adjustment and ±3 mm Linear Translation. Two of these adjusters include removable knobs, while the third must be tuned with a 2 mm hex key. The Top and Bottom of the mount with M4 Taps and M6 Taps for posts mounting.

Product characteristics
1. Design for mounting Φ 50.8 mm optics with minimum thickness of 6 mm.
2. Kinematic Tip and Tilt Adjustment, ±3 mm Linear Translation.
3. Mounts Φ2" (Φ50.8 mm) Optics at a 45° Angle to the Optical Axis.

Products Related Download

Size of Compatible Optics

Select..  

 50.8mm

Cage Rod Features

Select..  

Thread

Select..  

 M4/M6

Clear

Pro No.

Parameter

Size of Compatible Optics

Cage Rod Features

Thread

Delivery time

Compare

Price

Purchase

530048

Parameter list

50.8mm

6mmTapped-Holes

M4/M6

In stock



$158.33



530049

Parameter list

50.8mm

M3-Smooth-Bore-Holes

M4/M6

In stock



$158.33



30 mm to 60 mm Cage Plate Adapter

Φ2" Lens Tubes

60 mm Cage Mirror Mounts
