35mm 2/3" 2M Fixed Focal Length Lens

Price Option

Product No. 600003

Stock In Stock

Express DHL, Fedex etc.

Quantity

Add car Chating online

Product file downloadClick file to download

3D View CAD PDF Auto CAD DXF eDrawing Step Datesheet

Parameters Specification Data curve Related Products Description

Focal Length 35mm

F# 1.4

Max. sensor size 2/3"

Mount C

Resolution 2MP

Working Distance 0.3m～∞

Filter Thread M30.5×0.5mm

FOV 17.7°×14.2°×10.7°

Distrotion -0.33%@y=5.5mm

Weight 90g

No.	Item		Specifications
1	Max. sensor size		2/3"(11mm）
2	Focal Length		35mm
3	Mount		C-Mount
4	F/#		F1.4-C
5	Working Distance		0.3m～∞
6	FOV(Diagonal x H xV)	2/3"	17.7°×14.2°×10.7°
		1/2"	12.9°×10.4°×7.8°
		1/3"	9.7°×7.8°×5.8°
7	Object Size (at the minimum focus distance)	2/3"	94.4×75.2×56.2mm
		1/2"	68.3×54.5×40.8mm
		1/3"	51.1×40.8×30.6mm
8	BFL（in air）		14.70mm
9	Operation	Focus	Manual
		Aperture	Manual
10	Distortion	2/3"	-0.33%@y=5.5mm
		1/2"	-0.17%@y=4.0mm
		1/3"	-0.09%@y=3.0mm
11	Filter thread		M30.5×0.5mm
12	Lens Size(W x L)		40.5×46.49mm
13	Weight		90g
14	Work Temperature		-10℃～+50℃
15	Distance of entrance pupil		34.20mm
16	Diameter of entrance pupil		25mm
17	Distance of exit pupil		-35.79mm
18	Diameter of exit pupil		25.30mm
19	Total optical length		49.24mm
20	Magnification		-0.118

Focus Distance	Magnification	Front DOV(mm)	Back DOV(mm)
300mm	-0.11804	1.1571	1.1661
350mm	-0.10115	1.5740	1.5882
400mm	-0.08845	2.0545	2.0758
450mm	-0.07864	2.5985	2.6289
500mm	-0.07076	3.2060	3.2476
550mm	-0.06432	3.8768	3.9322
600mm	-0.05895	4.6107	4.6827
650mm	-0.05441	5.0477	5.4992
700mm	-0.05052	6.2677	6.3819
750mm	-0.04715	7.1904	7.3310

Curve Download

16mm 2/3" 2M Fixed Focal Length Lens

25mm 2/3" 2M Fixed Focal Length Lens

35mm 2/3" 2M Fixed Focal Length Lens

50mm 2/3" 2M Fixed Focal Length Lens

2/3" 2M FA lens covers all common focal lengths, suitable for a variety of simple imaging, with good performance and low cost, mainly used for large-scale industrial automation applications.
