Double-Concave (DCV) Lenses

 UV Fused Silica Double-Concave (DCV) Lenses

UV Fused Silica Double-Concave (DCV) Lenses

Double-Concave Lenses can diverge the light, its focal length is nedtive, which is made of two concave surfaces with same radius.These lenses are ideal for the application of beam expansion, light projection or the expansion of the focal length. Grand Unified Optics offers uncoated or AR coatings Double-Concave Lenses for your appliation.

Material UV Fused Silica

Design Wavelength 587.6nm

Diameter Tolerance +0.0 /-0.1mm

Center Thickness Tolerance ±0.2mm

Irregularity (P-V) λ/4 @632.8nm

Focal Length Tolerance（EFL） ±2%

Centering Tolerance 3 arcmin

Surface Quality 20-10

Bevel 0.2mmX45°

Coating As product list

Products Spectral curve Related Download

Dia

Select..  

EFL

Select..  

Coating

Select..  

Clear

Pro No.

Parameter

Dia

EFL

Coating

Delivery time

Compare

Price

Purchase

130052

Parameter list

6.30mm

-6.30mm

Uncoated

2.00mm

In stock



$39.17



130053

Parameter list

10.00mm

-10.00mm

Uncoated

2.00mm

In stock



$39.17



130054

Parameter list

12.70mm

-12.70mm

Uncoated

2.00mm

In stock



$39.17



130055

Parameter list

12.70mm

-15.00mm

Uncoated

2.40mm

In stock



$35.83



130056

Parameter list

25.40mm

-25.40mm

Uncoated

2.00mm

In stock



$49.17



130057

Parameter list

25.40mm

-30.00mm

Uncoated

2.00mm

In stock



$45.83



130058

Parameter list

25.40mm

-50.00mm

Uncoated

3.50mm

In stock



$45.83



130059

Parameter list

25.40mm

-75.00mm

Uncoated

3.50mm

In stock



$45.83



130060

Parameter list

25.40mm

-100.00mm

Uncoated

3.50mm

In stock



$45.83



130061

Parameter list

6.30mm

-6.30mm

AR@250~400nm

2.00mm

In stock



$47.50



130062

Parameter list

10.00mm

-10.00mm

AR@250~400nm

2.00mm

In stock



$47.50



130063

Parameter list

12.70mm

-12.70mm

AR@250~400nm

2.00mm

In stock



$47.50



130064

Parameter list

12.70mm

-15.00mm

AR@250~400nm

2.40mm

In stock



$44.17



130065

Parameter list

25.40mm

-25.40mm

AR@250~400nm

2.00mm

In stock



$62.50



130066

Parameter list

25.40mm

-30.00mm

AR@250~400nm

2.00mm

In stock



$59.17



130067

Parameter list

25.40mm

-50.00mm

AR@250~400nm

3.50mm

In stock



$59.17



130068

Parameter list

25.40mm

-75.00mm

AR@250~400nm

3.50mm

In stock



$59.17



130069

Parameter list

25.40mm

-100.00mm

AR@250~400nm

3.50mm

In stock



$59.17


