12mm 2/3" VIS-NIR Fixed Focal Length Lens
Share
WeChat
Scan and add Wechat

12mm 2/3" VIS-NIR Fixed Focal Length Lens

Price Option
 € 129.58 (EUR) ￡106.44 (GBP) ￥760.00 (RMB)

Product No. 601001

Stock Please Consult

Express DHL, Fedex etc.

Quantity
Add car Chating online
Product file downloadClick file to download
3D View CAD PDF Auto CAD DXF eDrawing Step Datesheet
Parameters Specification Data curve Related Products Description
Focal Length 12mm
F/# 1.8
Max. sensor size 2/3"
Mount C
Working Distance 0.1m～∞
Filter Thread M25.5x0.6mm
FOV 49.6°×39.4°×33.4°
TV Distrotion 0.50%
Weight 50g
  No. Item Specifications
1 Max. sensor size 2/3"(11mm)
2 Focal Length 12mm
3 Mount C-Mount
4 F/# F1.8-F16
5 Working Distance 0.15m~∞
6 FOV(Diagonal x H xV) 2/3" 49.6°×39.4°×33.4°
7 BFL（in air） 11mm
8 Operation Focus Manual
Aperture Manual
9 TV Distortion 2/3" 0.50%
10 Filter thread M25.5×0.5mm
11 Lens Size D29.5×40.9mm
12 Weight 50g
13 Work Temperature -10℃～+50℃
14 Magnification -0.0749

Working Distance Magnification Ring Thicknes FOV（mm）
2/3"
(8.45mm×7.07mm)		 1/1.8"
(7.38mm×4.92mm)		 1/2"
(6.22mm×4.67mm)
H V H V H V
25mm -0.3397 5mm 24.87  20.81  21.73  14.48  18.31  13.75
50mm -0.199 5mm 42.46  35.53  37.09  24.72  31.26  23.47
75mm -0.1407 1.5mm 60.06  50.25  52.45  34.97  44.21  33.19
100mm -0.1088 1mm 77.67  64.98  67.83  45.22  57.17  42.92
150mm -0.0749   112.82  94.39  98.53  65.69  83.04  62.35
200mm -0.0571   147.99  123.82  129.25  86.16  108.93  81.79
250mm -0.0461   183.30  153.36  160.09  106.72  134.92  101.30
300mm -0.0387   218.35  182.69  190.70  127.13  160.72  120.67
350mm -0.0333   253.75  212.31  221.62  147.75  186.79  140.24
400mm -0.0293   288.40  241.30  251.88  167.92  212.29  159.39
450mm -0.0261   323.75  270.88  282.76  188.51  238.31  178.93
500mm -0.0235   359.57  300.85  314.04  209.36  264.68  198.72
550mm -0.0214   394.86  330.37  344.86  229.91  290.65  218.22
600mm -0.0197   428.93  358.88  374.62  249.75  315.74  237.06
700mm -0.0169   500.00  418.34  436.69  291.12  368.05  276.33
800mm -0.0148   570.95  477.70  498.65  332.43  420.27  315.54
900mm -0.0132   640.15  535.61  559.09  372.73  471.21  353.79
1000mm -0.0119   710.08  594.12  620.17  413.45  522.69  392.44

Curve Download

16mm 2/3" VIS-NIR Fixed Focal Length Lens

25mm 2/3" VIS-NIR Fixed Focal Length Lens

35mm 2/3" VIS-NIR Fixed Focal Length Lens

50mm 2/3" VIS-NIR Fixed Focal Length Lens
GU Optics pushes out a new series lens, VIS-NIR FA Lens, its working wavelength covers visible light and near-infrared light. And its focal length covers 8mm, 12mm, 16mm, 25mm, 35mm, and 50mm. With high resolution design and compact structure, this series of lenses can be widely used in industrial automation, machine vision, PCB inspection, biology, medicine, environmental protection and other fields.
