1064nm 80MHz Acousto Optic Q Switch





Share

WeChat

Scan and add Wechat

1064nm 80MHz Acousto Optic Q Switch

Price Option Please Consult

Product No. 460002

Stock Please Consult

Express DHL, Fedex etc.

Quantity

Add car Chating online

Product file downloadClick file to download

Parameters Related Products Description

Material Quartz Crystal

Working Wavelength 1064nm

Transmittance (one way) ≥99.6%

Damage Threshold 1GW/cm²

Polarization State Linear Polarization

Aperture 2mm

RF Signal Frequency 80MHz

RF Signal Power Rating (Maximum) 15W

Sonic Mode Compression Wave

RF Signal Input Method SMA-F

Rise Time（10~90%） 113ns/mm

AR Coating Reflectivity ＜0.2%/surface

Diffraction Efficiency 85%

Diffraction Angle 14.9mrad

Standing Wave Ratio ＜1.2:1

Cooling Method Conduction Cooling

Storage Temperature （-20~70℃）

1064nm 27.12MHz Acousto Optic Q Switch

1064nm 27.12MHz Acousto Optic Q Switch

1064nm 27.12MHz Acousto Optic Q Switch Driver

1064nm 27.12MHz Acousto Optic Q Switch Driver

1064nm 40.68MHz Acousto Optic Q Switch

1064nm 40.68MHz Acousto Optic Q Switch

1064nm 40.68MHz Acousto Optic Q Switch Driver

1064nm 40.68MHz Acousto Optic Q Switch Driver

GU Optics has launched Acousto Optic Q Switches with a wavelength of 1064nm and RF signal frequencies of 27MHz, 41MHz and 80MHz. This series of products has the characteristics of compact structure, high laser damage threshold, high diffraction efficiency, etc. For applications in life sciences and other related fields, we can also provide customized services according to your application for different occasions.
