1064nm 40.68MHz Acousto Optic Q Switch





Share

WeChat

Scan and add Wechat

1064nm 40.68MHz Acousto Optic Q Switch

Price Option Please Consult

Product No. 460001

Stock Please Consult

Express DHL, Fedex etc.

Quantity

Add car Chating online

Product file downloadClick file to download

Parameters Related Products Description

Material Quartz Crystal

Working Wavelength 1064nm

Transmittance (one way) ≥99.6%

Damage Threshold 1GW/cm²

Polarization State Linear Polarization

Aperture 2mm

RF Signal Frequency 40.68MHz

RF Signal Power Rating (Maximum) 20W

Sonic Mode Compression Wave

RF Signal Input Method SMA-F

Rise Time（10~90%） 113ns/mm

AR Coating Reflectivity ＜0.2%/surface

Diffraction Efficiency 85%

Diffraction Angle 7.5mrad

Standing Wave Ratio ＜1.2:1

Cooling Method Conduction Cooling

Storage Temperature （-20~70℃）
