1064nm 27.12MHz Acousto Optic Q Switch





Share

WeChat

Scan and add Wechat

1064nm 27.12MHz Acousto Optic Q Switch

Price Option Please Consult

Product No. 460000

Stock Please Consult

Express DHL, Fedex etc.

Quantity

Add car Chating online

Product file downloadClick file to download

Parameters Related Products Description

Material Fused Silica

Working Wavelength 1064nm

Transmittance (one way) ≥99.6%

Damage Threshold 1GW/cm²

Polarization State Arbitrary Polarization State

Aperture 2mm

RF Signal Frequency 27.12MHz

RF Signal Power Rating (Maximum) 50W(Mixed Wave Mode);100W(Shear Wave Mode)

RF Signal Input Method BNC

Thermal Safety Interface SMC

Operating Mode Raman-Nas Diffraction

Diffraction Efficiency ＞60%

Diffraction angle 3.32mrad

Input Impedance 50Ω

Standing Wave Ratio ＜1.2:1

Cooling Water Flow Rate ＞190cc/Min

Operating Temperature 10~40℃

Storage Temperature 0~50℃
