- Material Fused Silica
- Diameter Tolerance ＋0.0/-0.1mm
- Mount Thickness 3.5mm
- Substrate Thickness 2.0mm（* Thickness 1.05mm）
- Substrate Thickness Tolerance ±0.1mm（* Thickness Tolerance±0.05mm）
- Surface Quality 60-40
- AOI 0±5°
- Note Arrow on ring indicates preferred direction of propagation of light
CWL
Transmission Band
- Tavg＞90%@ 415-455 nm
- Tavg＞90%@ 425-465 nm
- Tavg＞93%@ 429.5-474.5 nm
- Tavg＞90%@ 453-467 nm
- Tavg＞90%@ 430-490 nm
- Tavg＞93%@ 446-486 nm
- Tavg＞90%@ 457.5-492.5 nm
- Tavg＞90%@ 465 - 485 nm
- Tavg＞93%@ 450-500 nm
- Tavg＞93%@ 469.5-494.5 nm
- Tavg＞93%@ 464.5-499.5 nm
- Tavg＞93%@ 473-491 nm
- Tavg＞90%@ 489-531 nm
- Tavg＞93%@ 505-515 nm
- Tavg＞93%@ 502.5-537.5 nm
- Tavg＞90%@ 490-550 nm
- Tavg＞93%@ 485-555 nm
- Tavg＞93%@ 506-534 nm
- Tavg＞90%@ 517.5-532.5 nm
- Tavg＞90%@ 505.5-544.5 nm
- Tavg＞93%@ 502.5-547.5 nm
- Tavg＞93%@ 500-550 nm
- Tavg＞93%@ 547.5-572.5 nm
- Tavg＞90%@ 513-607 nm
- Tavg＞93%@ 554-568 nm
- Tavg＞90%@ 565 - 584 nm
- Tavg＞93%@ 545-604 nm
- Tavg＞93%@ 562.5-587.5 nm
- Tavg＞93%@ 605-625 nm
- Tavg＞90%@ 594-646 nm
- Tavg＞90%@ 617.5-632.5 nm
- Tavg＞93%@ 580-670 nm
- Tavg＞93%@ 643.5-656.5 nm
- Tavg＞90%@ 647.5-662.5 nm
- Tavg＞90%@ 651-671 nm
- Tavg＞93%@ 672-712 nm
- Tavg＞93%@ 690-730 nm
- Tavg＞93%@ 696-736 nm
- Tavg＞93%@ 705-845 nm
- Tavg＞93%@ 752-798 nm
- Tavg＞93%@ 813.5-850.5 nm
- Tavg＞93%@ 845-855 nm
- Tavg＞93%@ 695-1005 nm
- Tavg＞90%@
FWHM(Nominal)
- 15nm
- 18.4nm
- 18.7nm
- 20.1nm
- 20.8nm
- 23.7nm
- 24.4nm
- 24.7nm
- 24.8nm
- 25.6nm
- 26.2nm
- 26.3nm
- 30.1nm
- 31.3nm
- 32.3nm
- 34.7nm
- 39.1nm
- 40.1nm
- 40.7nm
- 44.9nm
- 45.3nm
- 45.4nm
- 47nm
- 47.1nm
- 47.2nm
- 47.5nm
- 47.6nm
- 48.4nm
- 50.5nm
- 50.6nm
- 54.7nm
- 55.7nm
- 55.9nm
- 58.2nm
- 64.2nm
- 66.2nm
- 68nm
- 76.5nm
- 97.2nm
- 99.9nm
- 146.3nm
- 319.2nm
