40x40mm 1-Axis Priecision Stages
Price Option
Product No. 516300
Stock In Stock
Express DHL, Fedex etc.
Product file downloadClick file to download
- Platform Size 40x40mm
- Travel ±6.5mm
- Min Micrometer Graduations 10μm
- Straight Line Accuracy 3μm
- Load Capacity( 1.8kgf
- Weight 0.14kg
Single Linear (X)-Axis;
Stage Size : 40、60、80 (mm);
Travel : ±6.5 ~±12.5 (mm);
Bearing Type : V-Grooved and Crossed-Roller Bearings for High Load Capacity and Low Angular Deviation;
Integrated Micrometer Mounts, Support precision motion and high load capacities.;
Material: Aluminium alloy;
