40x40mm Precision Stainless Stages





Share

WeChat

Scan and add Wechat

40x40mm Precision Stainless Stages

Price Option

Product No. 516401

Stock In Stock

Express DHL, Fedex etc.

Quantity

Add car Chating online

Product file downloadClick file to download

CAD PDF Auto CAD DXF eDrawing Step

Parameters Related Products Description

Platform Size 40x40mm

Travel ±6.5mm

Min Micrometer Graduations 10μm

Straight Line Accuracy 3μm

Load Capacity 10kgf

Weight 0.23kg

40x40mm Precision Stainless Stages

60x60mm Precision Stainless Stages

65x65mm Precision Stainless Stages

80x80mm Precision Stainless Stages

Single Linear (X)-Axis; Stage Size : 40、60、80 (mm); Travel : ±3.2~±12.5 (mm); Guide System: Their rigid all-steel construction and heavy-duty cross-roller bearings provide uniform performance over the entire range of motion.; Integrated Micrometer Mounts, Support precision motion and high load capacities.; Material: Stainless Construction, corrosion and heat resistance.
