LD PUMPED ALL-SOLID-STATE ACOUSTO-OPTIC Q-SWITHED LASER 355nm 1~100mW
Price Option
Please Consult
Product No. 470007-1
Stock Please Consult
Express DHL, Fedex etc.
Product file downloadClick file to download
- Wavelength 355±1nm
- Operating Mode Acousto-Optics-Q-switched
- Output Power 1~100mW
- Power Stability(rms,over 4 hours) ＜3%,＜5%,＜10%
- Single Pulse Energy 1~40(40μJ @1kHz; 10μJ @5kHz)
- Pulse Duration 5~10ns@＜10kHz
- Beam Divergence, full angle ＜1.5mrad
- Beam Diameter ~1.2mm
- Rep. Rate 0.1~20KHz
- Beam Height From Base Plate 45mm
- Warm-up Time ＜10 min
- Operating Temperature 10-35℃
| 470007-1 | 470007-2 | |
| Wavelength (nm) | 355±1 | |
| Operating mode | Acousto-Optics Q-switched | |
| Single pulse energy (μJ) | 1~40 (40μJ @1kHz; 10μJ @5kHz) |
|
| Rep. rate (kHz) | 0.1~20 | |
| Pulse duration | Typically 5~10ns @<10kHz, varies from power and repetition. | |
| Average power (mW) | Average power (mW)= Single pulse energy (μJ)* Rep. rate(kHz) |
|
| Power Stability (rms,over 4 hours) | <3%,<5%,<10% | |
| Transverse mode | Near TEM00 | |
| M2 factor | <1.5 | |
| Beam Diameter at the aperture 1/e2 (mm) | ~1.2 (optional) | ~0.3 |
| Beam divergence, full angle (mrad) | <1.5 (optional) | <5.0 |
| Polarization ratio | >100:1 Horizontal±5 degree | |
| Warm-up Time (minutes) | <10 | |
| Beam height from base plate (mm) | 25 | |
| Operating temperature(℃) | 10~35 | |
| Power supply (90-264VAC) | 4600P5 | |
| Expected lifetime (hours) | 10000 | |
| Warranty | 1 year | |
