60×60mm High Precision Crossed-Roller Bearing Linear Translation Stages-Vertical





  Likes

Share

WeChat

Scan and add Wechat

60×60mm High Precision Crossed-Roller Bearing Linear Translation Stages-Vertical

Price Option

Product No. 516753

Stock In Stock

Express DHL, Fedex etc.

Quantity

Add car Chating online

Product file downloadClick file to download

CAD PDF Auto CAD DXF eDrawing Step

Parameters Related Products Description

Platform Size 60x60mm

Travel ±6.5mm

Min scale 0.01mm

Parallelism 30μm

Straight Line Accuracy 10μm

Load Bearing 19.6N

Weight 0.47Kg

3-Axis Precision Translation Stages-Left

40×40mm High Precision Crossed-Roller Bearing Linear Translation Stages

60×60mm High Precision Crossed-Roller Bearing Linear Translation Stages

80×80mm High Precision Crossed-Roller Bearing Linear Translation Stages

* Linear crossed roller bearing design, which provides a high accuracy,high load capacity and Linear function * Rails are made of polished bearing steel, to ensure the smoothness and accuracy of long-term use * There is a set of pre-pressing springs which can impede the top of the micrometer head to eliminate the gap. * M6 and M4 Mounting Holes are convenient for combined or fixed * Push the micrometer head to the desired position, tighten the small screw on the side of each axis to fix it well * Micrometer head was designed on the side, save the space * Travel : 13mm or 25mm * Angular deviation: up and down pitch<25arcsec; Left and right yaw<15arcsec *Minimum scale value of Micrometer: 0.01mm * With locking function,easy to fix on other components or optical tables.
