Home  Products  Pulsed Laser  470009

NANOSECOND PULSED VIOLET DIODE LASER 405nm 1~500mW





  Likes

Share

WeChat

Scan and add Wechat

NANOSECOND PULSED VIOLET DIODE LASER 405nm 1~500mW

Price Option Please Consult

Product No. 470009

Stock Please Consult

Express DHL, Fedex etc.

Quantity

Add car Chating online

Product file downloadClick file to download

Parameters Related Products Description

Wavelength 405±5nm

Operating Mode Pulsed

Output Power 1~500mW

Power Stability(rms,over 4 hours) /

Single Pulse Energy /

Pulse Duration ＞10ns, 20ns, …,10ms

Beam Divergence, full angle ＜1.0mrad

Beam Diameter ~1.2mm

Rep. Rate 1Hz-80MHz(1Hz-25MHz，by using CNI Multifunctional Pulse Trigger）

Beam Height From Base Plate 19mm

Warm-up Time ＜5 min

Operating Temperature 10-35℃

LD PUMPED ALL-SOLID-STATE UV LASER 266nm 1~30mW

LD PUMPED ALL-SOLID-STATE UV LASER 266nm 30~120mW

LD PUMPED ALL-SOLID-STATE UV LASER 266nm 10mW

MODE-LOCKED PICOSECOND PULSED LASER 266nm 1~50mW

Central wavelength (nm)	405±5
Output power@3.3VDC (mW, CW)	>1, 10, 20, …,500
Pulse width (FWHM)	>10ns, 20ns, …,10ms
Transverse mode	Near TEM00
Noise of amplitude(rms, CW)	<1%
M2 factor	<1.2
Beam diameter at the aperture (1/e2,mm)	~1.2
Beam divergence, full angle (mrad)	<1.0
Polarization ratio	>50:1 (>100:1, optional) Horizontal±5 degree (Vertical Optional)
User trigger frequency (Multifunctional Pulse Trigger optional)	1Hz-80MHz (1Hz-25MHz by using CNI Multifunctional Pulse Trigger)
Rise Time (ns)	<3
Fall Time (ns)	<3
Modulation Depth (extinction ratio)	>1000000:1
Warm-up Time (minutes)	<5
Beam height from base plate (mm)	19
Operating temperature (℃)	10~35
Input voltage	+12VDC
Expected lifetime (hours)	10000
Warranty	1 year
